Performance Parameters

Dimension Weight

Length70m* Width 70m* Height 30m

Physical and mechanical properties of gas rib

Penetration resistance：≥1000N;

Environmental adaptation

1) Temperature resistance: working temperature: – 43℃~+50℃; storage temperature: -45℃~+70℃.

2) Waterproofing: rainfall intensity ≥2mm/min, 3h without leakage, 5h without dripping;

3) Salt spray resistance: No discoloration, powdering,or cracking after 150 hours; It can resist the impact of salt spray corrosion environmental conditions in coastal areas of China;

4) Resistance to moisture and heat: ≤ 2 levels.

5) Load resistance: can withstand 100mm of light snow.

6) Wind resistance: able to withstand strong winds with a wind speed of ≥ 20.7m/s (level 8)

Assemble& Disassemble Time

Assemble time ≤ 16 h (12 persons); disassemble time ≤ 12 h (12 persons)

Reliability

One-time inflation can maintain working pressure for ≥ 60 days, with a service life of no less than 5 years;

Maintainability

Base-level maintenance ≤ 0.5h.

Supportability

1) Equipped with professional maintenance tools;

2) All kinds of interfaces can be reserved according to system planning.

The product has passed ISO9001:2015 quality management system certification
