| G4T | |
| Product Structure: | 4-ply in 0°/90/0°/90° ,laminated |
| Fiber: | Teijin Twaron 2020 2200dtex |
| Areal Density： | 230±5 g/m² |
| width: | ≤160cm |
| Length: | ≥100 m Continuous |
| Test Data for 9mm V50: | 5.3kg/m²(m/s)>530 |
| Test for 44: | The deformation is less than or equal to 37mm for 25 layers. |
| This model uses a relatively hard matrix, which performs a less deformation effect during testing. | |
| G4TS | |
| Product Structure: | 4-ply in 0°/90/0°/90° ,laminated |
| Fiber: | Teijin Twaron 2020 2200dtex |
| Areal Density： | 230±5 g/m² |
| width: | ≤160cm |
| Length: | ≥100 m Continuous |
| Test Data for 9mm V50: | 5.3kg/m²(m/s)>530 |
| Test for 44: | The deformation is less than or equal to 37mm for 26 layers |
| This model uses a relatively soft matrix, making the UD product more comfortable when applied in soft ballistic vests. | |
| G2T | |
| Product Structure | 2-ply in 0°/90° laminated |
| Fiber | Teijin Twaron 2020 2200dtex |
| Areal Density | 195±5 g/m² |
| Width | ≤160cm |
| Length | ≥100m Continuous |
| Test for A4 | 29 layers |
| This model uses a relatively hard matrix, which performs a less deformation effect during testing. | |
| G2TS | |
| Product Structure | 2-ply in 0°/90° laminated |
| Fiber | Teijin Twaron 2020 2200dtex |
| Areal Density | 195±5 g/m² |
| Width | ≤160cm |
| Length | ≥100m Continuous |
| Test for A4 | 30 layers |
| This model uses a relatively soft matrix, making the UD product more comfortable when applied in soft ballistic vests. | |
