Technical Parameters

Weight

≤250g/m²

Physical & Mechanical Properties

Rupture strength: Warp ≥ 500N, Weft ≥ 500N;

Tear strength: Warp≥ 50N, Weft≥ 50N;

Flame retardant properties

Re-ignition time no more than 10s;

Camouflage performance

1) Protection band: 380nm~1200nm;

2) Gloss: each camouflage color 60 ° gloss is not greater than 5 gloss units;

3) Visibility: each camouflage unit obscures no more than 50 percent of the target’s visibility;

4) Light reflection properties

①Similar image characteristics to the corresponding background on visible and near-infrared images, with a combined luminance contrast of no more than 0.2;

② In the wavelength interval of not more than 10nm at each detection wavelength, and its corresponding background dominant color between the spectral reflectance contrast in the visible wavelength band is not greater than 0.1, and not more than 0.2 in the near-infrared wavelength band;

Environmental adaptation

The color difference before and after 500h artificial climate aging is less than 3 levels;

Life span

1) A storage lifespan is not less than 10 years;

2) A cumulative field lifespan is not less than 5 year
